OKUMA LB3000 EX II
| ∅ max | LENGHT MAX | MAX BAR DIAMETER |
|---|---|---|
| 250 mm | 800 mm | 75 mm |
VIEW VIDEO
MURATEC MT 200
| bar passage | ø max turning | max length |
|---|---|---|
| ø 65 | 160 mm | 200 mm |
Note: 27 driven tool stations – Portal for loading / unloading
VIEW VIDEO
TAKISAWA TMM250
| ∅ max | lenght max | max bar diameter |
|---|---|---|
| 300 mm | 700 mm | 75 mm |
Note: 30 motorized tool stations for milling and tapping with 4″ axis and variable Bar and rod loader
TAKISAWA BT25Y
| ∅ max | lenght max | max bar diameter |
|---|---|---|
| 230 mm | 530 mm | 76 mm |
BIGLIA 501
| ∅ max | lenght max | max bar diameter |
|---|---|---|
| 230 mm | 500 mm | 68 mm |
BIGLIA B700
| ∅ max | lenght max | max bar diameter |
|---|---|---|
| 200 mm | 600 mm | 54 mm |
BIGLIA 1000
| ∅ max | lenght max | max bar diameter |
|---|---|---|
| 300 mm | 1000 mm | 75 mm |
BIGLIA B1200
| ∅ max | lenght max | mac bar diameter |
|---|---|---|
| 400 mm | 1100 mm | 90 mm |
Note: 12 motorized tool stations
CNC CENTRES
OKUMA MB-66V
| bottom platf. with revolving table | bottom platf. without revolving table |
|---|---|
| 1200 x 660 x 550h mm | 1500 x 660 x 660h mm |
Extra: inner induction – wharehouse 48 tools
MORI SEIKI NV500
| bottom platf. with revolving table | bottom platf. without revolving table |
|---|---|
| 1200 x 700 x 620h mm | 1500 x 700 x 720h mm |
Extra: change pallet – inner induction – wharehouse 30 tools
PERFORMA CLASSIC V PLUS XP
| X Axis | Y Axis | Z Axis |
|---|---|---|
| 760/30 mm | 435/17 mm | 520/21 mm |
QUALITY CHECK
AXIOM TOO CNC
| X AXIS | Y AXIS | Z AXIS |
|---|---|---|
| 640 mm | 900 mm | 500 mm |
VIEW VIDEO
OTHER MACHINE
Balancing CEMB ZE12
| ø balancing | weight material | L max |
|---|---|---|
| da 20 a 350 mm | da 1 a 100 kg | 1100 mm |
Threading ORT 18
| threading pitch |
|---|
| da M4 a M36 |
Welding position CNC
| working area | lenght |
|---|---|
| ø 200 mm | 1000 mm |
